13X APG molecular sieve
Model Number:BS-13X APG
Place of Origin:Pingxiang,China
Keywords:13X APG molecular sieve, 13X APG zeolite, 13X desiccant
Type 13X APG molecular sieve is specially designed to co-absorb CO2 and H2O for air cryo-separation industry.
INQUIRE NOW
Contact us
86 (0) 799 6699600 / 0086 15179934828
jenny@bestpacking.cn
Type 13X APG molecular sieve is specially designed to co-absorb CO2 and H2O for air cryo-separation industry. It has largeer capacity and faster adsorption speed for removal of CO2 and H2O to prevent the bed gelation, it is suitable for any air cryo-separation plants of any size and any types in the world.
Typical Chemical Formula
Na2O Al2O3 2.45SiO2 6.OH2O
SiO2 : Al2O3 ≈2.6-3.0
Technical Parameter
Item |
Unit |
Technical data |
|||
Shape |
|
Pellet |
Sphere |
||
Diameter |
mm |
1.5-1.7 |
3.0-3.3 |
1.7-2.5 |
3.0-5.0 |
Size ratio up to grade |
% |
≥98 |
≥98 |
≥96 |
≥96 |
Bulk density |
g/ml |
≥0.62 |
≥0.61 |
≥0.64 |
≥0.64 |
Wear ratio |
% |
≤0.20 |
≤0.20 |
≤0.10 |
≤0.10 |
Crushing strength |
N |
≥30/cm |
≥70/cm |
≥50/piece |
≥70/piece |
Static water adsorption |
% |
≥27 |
≥27 |
≥27 |
≥27 |
CO2 adsorption |
% |
≥18.5 |
≥18.5 |
≥18.5 |
≥18.5 |
Water content, as shipped |
% |
≤1.5 |
≤1.5 |
≤1.5 |
≤1.5 |
Typical Application
Removal of H2O from air fro air cryo-separation application.
Size
13X APG- Zeolites are available in beads of 1-2 mm, (10x18 mesh) 2-3 mm, (8x12 mesh) , 2.5-5 mm, (4x8 mesh) and as powder, and in pellet 1.6”, 3.2”.
Attention
To avoid damp and pre-adsorption of organic before running, or must to be reactivated.
